Aug 27, 2014 - The software works on any OS, but the drivers are the problem so instead they. MINI VCI cable for TOYOTA TIS Techstream. Casing and “MINI-VCI J2534 Standard OBDII Communication Interface” sticker. Mine is actually Windows 7 x64, but for Windows 8 the configuration., 10:48 PM. Feb 13, 2018 - I bought a cheap Chinese Mini VCI J2534 cable for diagnostics and auto settings. And the program itself-Toyota Techstream with V10.10.018 version. How to install the driver and the program under Windows 7 or 8.1 x64.
This is TOYOTA TIS Techstream 10.30.029 update and installation guide. Tis v10.30.029 has been successfully on mini vci (for 22pin), new mini vci,
xhorse mvci, mangoose, vxdiag vcx nano for toyota.
And you can download the newest Toyota TIS Techstream Here:
Password:autoprofessionals.org
Software ID: 85B100F0EE0B98618562A04D9570C301
Operating system requirement:
XP or “XP Mode” in Windows 7 (except win 7 home)
A part of users use VMware and XP Professional.
Languages available:
Chinese, English,French, German, Italy, Japanese, Spanish
Techstream compatible tools:
New MINI VCI for Toyota TIS Techstream V10.10.018
MINI VCI for Toyota TIS Techstream with Toyota 22Pin
Mangoose interface
Original Xhorse MVCI 3 in 1
WIFI VXDIAG VCX NANO for TOYOTA
How to install TIS 10.30.029:
*Video guide:
*Step-by-step instruction:
Step 1- install Toyota Teachstream
Open “Toyota Techstream 10.30.029.exe”
Select a steup language to go on
Click Next
Accept the agreement to go on
Customer information: click Next
Click Install to begin installation of Techstream 10.30.029
Finish installing Techstream
Step 2- install MVCI driver for TIS
Open “MVCI Driver for Toyota”
Click Next
Click Install to begin installation of the MVCI driver for TIS
Finish installing MVCI driver for TIS
Step 3- paste and replace Main Menu
Copy “MainMenu” application
Open Techstream Properties
Click Find Target
Paste “MainMenu” application in C:/program files/toyota diagnostics/techstream/bin, confirm file replace
Close bin folder and Techstream Properties
Connect the device (new Mini VCI, mini VCI for Toyota 22 pin, MVCI,Mangoose techstream, VXDIAG NANO) to the vehicle and then install the driver
Open “Techstream” on Desktop
Click No
Select Setup->Techstream configuration
Select an area (here: Europe), click Next
Select a language (here: English), click Next
Techstream configuration, click OK
open Desktop folder “Toyota Techstream”->notepad “serie”
Copy the key
Click Connect to vehicle in Techstream interface
Paste as the New Key when register Techstream software, click OK
Finish Option (here: VIOS, China & 1205-), click Next
Select Engine and ETC to continue
Trouble codes display
Select Data list on the left menu
(Lost communication with vehicle: click Retry)
Click Close->Main Menu->Log out (Techstream)
Save
Save
Save
UOBDII Official Blog All rights reserved TOYOTA TIS Techstream 10.30.029 Free download &Update Guide
Mini Vci J2534 Driver Windows 10 0
Related posts:
I bought a cheap Chinese Mini VCI J2534 cable for diagnostics and auto settings. I used it and found that you can do a lot with it through the Toyota Techstream service program.
And here he came to me:
Package includes the drivers for the cable and the program itself-Toyota Techstream with V10.10.018 version.
Cable for diagnosis Mini-VCI J2534
I post links for download: Toyota Techstream 10.10.018 , drivers MVCI_Driver_for.msi
Then I will tell you how to install the driver and the program under Windows 7 or 8.1 x64.
The instruction can be found on the Internet , but I will write it here.
INSTALLATION INSTRUCTIONS Techstream on Windows 7, 8.1 – x64 bit
If you bought the MINI VCI J2534 cable and there is no unpacked driver on the disk, and there is only the MVCI Driver for TOYOTA.msi installer that does not really work when installed on any Windows x64 and gives an error, and it must be installed, otherwise the sw will not work, and it does not matter. This problem can be solved by installing the MVCI Driver for TOYOTA.msi manually as follows:
1. Create a folder on drive C: Temp
2. Copy to our C: Temp folder our MVCI Driver for TOYOTA.msi file
3. With Administrator rights open and run the following command:
msiexec / a “C: temp MVCI Driver for TOYOTA.msi” / qb TARGETDIR = c: temp mvci
this command will extract all content from the MSI file to the C: Temp mvci folder
4. We delete the file MVCI Driver for TOYOTA.msi from the folder C: Temp mvci, it is no longer needed, we can also remove it from the folder C: Temp
5. We go in C: Program Files (x86) and create there folder XHorse Electronics and in it one more MVCI Driver for TOYOTA TIS and move there all the contents from the folder C: Temp mvci
6. Connect the MINI VCI cable to the USB port.
IMPORTANT: When the automatic driver installation process starts, it must be canceled and the device will not be detected.
7. Open the Device Manager and locate the two faulty devices in the list. They will have a yellow icon indicating that Windows could not install the drivers for them. Now right click on the faulty device, select “Update Driver”, then “search on this computer” next “Browse my computer” … and specify the path to “C: Program Files (x86) XHorse Electronics MVCI Driver for TOYOTA TIS “(” include subfolders “check box). Click the “Next” button and wait for the drivers to be installed.
Now you should see two new devices: “Controllers USB USB Serial Converter” and “Ports (COM & LPT) USB Serial Port (COM —)”. Where instead of a line will be your figure COM port.
8. Next, go to the path “C: Program Files (x86) XHorse Electronics MVCI Driver for TOYOTA TIS” and run the file “FirmwareUpdateTool.exe”.
In the opened program, click the “Device Info” button. You should see the “connected device” graph filled.
If you see this, then your MINI VCI works under a 64-bit version of Windows and can be used by other programs, such as Techstream.
There is a connection with the cable!
9. Now install Techstream using the software “Techstream.exe” of any version. after installation do not run it yet.
10. To activate it, you need to change the TISFunction = 1 line in the C: Program Files Toyota Diagnostics Techstream Env IT3System.ini file and change it to “0” and save the file.
Now you need to make the program see the cable
So that Techstream sees MINI-VCI under Windows x64, the Registry should be changed like this:
1. Open the Windows Registry Editor, on Windows 8.1 x64, the path is:
[HKEY_LOCAL_MACHINE SOFTWARE PassThruSu pport.04.04 DENSO CORPORATION – TIS Techstream VIM]
But there must definitely be a folder PassThruSupport.04.04 and it has a subfolder (I have DENSO CORPORATION – TIS Techstream VIM) it should have the following parameters
: “Name” = “XHorse – MVCI”
“Vendor” = “XHorse ELECTRONICS Co., Ltd.”
“ConfigApplication” = “C: Program Files (x86) XHorse Electronics MVCI Driver for TOYOTA TIS FirmwareUpdateTool.exe”
“FunctionLibrary” = “C: Program Files (x86) XHorse Electronics MVCI Driver for TOYOTA TIS MVCI32.dll ”
” APIVersion “=” 04.04 ”
” ProductVersion “=” 1.1.0 ”
“J1850VPW” = dword: 00000001
“J1850PWM” = dword: 00000001
“ISO9141” = dword: 00000001
“ISO14230” = dword: 00000001
“CAN” = dword: 00000001
“ISO15765” = dword: 00000001
“SCI_A_ENGINE” = dword: 00000000
” SCI_A_TRANS “= dword: 00000000
” SCI_B_ENGINE “= dword: 00000000
” SCI_B_TRANS “= dword: 00000000
Also there is a section
[HKEY_LOCAL_MACHINE SOFTWARE PassThruSupport.04.04 DENSO CORPORATION – TIS Techstream VIM Parameter]
“Baudrate” = dword: 0001c200
“Comport” = dword: 00000005
“Connect” = dword: 00000000
“Interface” = “AUTOMATIC”
” Firmware “=” x ”
” LE “= dword: 00000000
” LN “= dword: 00000001
” SN “= dword: 00000000
But you can manually do nothing, but simply make changes to the registry by downloading and running this file .
2. Launch Techstream. Go to Setup VIM select will open the menu in it should be “XHorse-MVCI”
3. Connect the MVCI cable to the USB interface, start the program, then click “Connect to Vehicle” in Toyota Techstream. If everything works, you will be asked to confirm the car / year / model, and if you connect to the car and start it, you will get access to the diagnostic interface.
The first thing to do was to turn off the orange American DRLs. other features stay tuned!
